Fluke | Digital Multimeter

Fluke 87V Industrial Multimeter

The Fluke 87V Industrial Multimeter is designed for high-accuracy measurements, ideal for troubleshooting complex industrial systems. It features true RMS for precise AC voltage and current readings, captures intermittent signals as fast as 250 µS with Peak Capture, and supports voltage measurements up to 1000 V with CAT III 1000 V and CAT IV 600 V safety ratings. The 87V's rugged build, including a removable holster and enhanced safety features, makes it perfect for work in harsh environments..

  • Detail
  • Special Features
  • Specification

The Fluke 87V Industrial Multimeter is engineered to offer precision in environments with high electrical noise and fluctuating signals. It supports various measurement functions including AC/DC voltage, current, resistance, capacitance, frequency, and temperature. The meter also features a rugged design with an IP67 rating for waterproofing and dustproofing, making it ideal for harsh work environments like power distribution, motor drives, and automation systems. With additional features like peak capture, low-pass filtering for VFDs, and high-resolution displays, it provides versatile and reliable performance. The 87V is built to meet the highest safety standards, ensuring safe operation in critical industrial applications.

  • True RMS Measurement: Accurate readings for complex signals and non-linear loads.

  • Peak Capture: Captures intermittent signals as fast as 250 µS, essential for diagnosing problems with fluctuating signals.

  • Low-Pass Filter: Supports accurate voltage measurements on VFDs and other electrically noisy equipment.

  • Rugged, Industrial Design: IP67-rated with drop resistance up to 4 meters (13 feet), perfect for harsh industrial environments.

  • Enhanced Safety Features: Includes a built-in audible Input Alert and meets the latest EN 61010-1 safety standards for CAT III 1000 V and CAT IV 600 V environments.

  • Easy Access Battery Door: Fast battery changes without disrupting calibration settings.

  • Backlit Display & Keypad: Clear and easy-to-read measurements even in low-light conditions.

  • Touch Hold: Keeps readings on the display even after removing the probes.

  • Removable Holster: Offers added protection and holds test leads for easy storage.

Function Range Resolution Accuracy
DC Voltage 0.1 mV to 1000 V 0.001 V - 1 V ±(0.05% + 1)
AC Voltage 0.1 mV to 1000 V 0.01 V - 1 V ±(0.7% + 2) True RMS
AC Millivolts 400.0 mV 0.1 mV 3.0% + 3
DC Millivolts 400.0 mV 0.1 mV 1.0% + 10
Diode Test 2.000 V 0.001 V ±(1% + 1)
Resistance 0.1 Ω to 50 MΩ 0.1 Ω - 0.01 MΩ ±(0.5% + 3) to ±(1.5% + 3)
Capacitance 0.01 nF to 9999 μF 0.01 nF - 1 μF ±(1% + 2)
Frequency 0.5 Hz to 199.99 kHz 0.01 Hz - 0.1 kHz ±(0.005% + 1)
Duty Cycle 1% to 99% 0.1% ±(0.2% per kHz + 0.1%)
AC Current μA (40 Hz to 400 Hz) 400.0 μA - 4000 μA 0.1 μA - 1 μA 1.5% + 3
AC Current mA (40 Hz to 400 Hz) 40.00 mA - 400.0 mA 0.01 mA - 0.1 mA 1.5% + 3
DC Current μA 400.0 μA - 4000 μA 0.1 μA - 1 μA 1.5% + 3
DC Current mA 40.00 mA - 400.0 mA 0.01 mA - 0.1 mA 1.5% + 3
Temperature -200 °C to 1090 °C 0.1 °C ±2% ±1 °C
Backlight - - Yes
